Product Introduction:

The 48kWh Stackable Battery System is a scalable and flexible energy storage solution designed for both residential and commercial applications. It consists of three 16kWh LiFePO4 battery modules, which can be stacked to expand capacity, and comes integrated with a high-performance 11kW inverter.

This system is ideal for solar energy storage, off-grid applications, and backup power. The stackable modular design allows easy installation, expansion, and maintenance, while the intelligent BMS (Battery Management System) ensures multiple protections, including overcharge, over-discharge, over-current, short-circuit, and temperature monitoring.

The LiFePO4 chemistry guarantees high safety, long cycle life (6000+ cycles at 80% DOD), and stable performance. Combined with the 11kW inverter, the system provides seamless energy conversion, supporting smart load management, peak shaving, and backup power supply.

Key Features

High Capacity & Scalability: 48kWh system (3 × 16kWh modules), expandable to meet larger energy demands.

Integrated Hybrid Inverter: 11kW inverter for efficient energy conversion, supporting off-grid applications.

Safe & Reliable: LiFePO4 battery cells with 6000+ cycles, intelligent BMS for comprehensive protection.

Modular & Stackable Design: Easy to install, transport, and expand.

All-in-One Solution: Battery + inverter system for solar, residential, and small commercial energy storage.

Durable & Eco-Friendly: IP65-rated enclosure, compliant with CE, UN38.3, MSDS certifications.

Technical Specifications

Total Capacity: 48kWh (16kWh × 3 modules)

Nominal Voltage: 51.2V per module

Nominal Capacity:314Ah

Cell Type: LiFePO4 (Lithium Iron Phosphate)

Cycle Life: ≥6000 cycles @ 80% DOD

Inverter Power: 11kW Inverter

Enclosure: Metal / Aluminum Alloy, IP65 protection

Operating Temperature: Charging 0-60℃,discharging -20-60℃

Applications

Solar Energy Storage, Home Energy Storage, Commercial Backup Power, Off-grid Systems
